code name
|
MBUR120
|
MBUR150
|
MBUR180
|
|
power
|
22-50HP
|
22-50HP
|
40-80HP
|
|
Mowing width
|
1140mm
|
1455mm
|
1735mm
|
|
Total width
|
1255mm
|
1550mm
|
1850mm
|
|
Grass height
|
20-120mm
|
20-120mm
|
20-120mm
|
|
Number of blades (pieces)
|
2
|
2
|
2
|
|
Blade size
|
475x75x12mm
|
620x75x12mm
|
790x75x12mm
|
|
Blade line speed
|
62m/s
|
60m/s
|
71m/s
|
|
Panel thickness
|
2.3mm
|
2.5mm
|
3.5mm
|
|
Tailwheel size
|
95mm width×390mm day
|
95mm widthx 390mm day
|
95mm widthx 390mm day
|
|
gearbox
|
1:1.46 ratio-Cast Iron Housing with Beveled Gers
|
1:1.46 ratio-Cast Iron Housing with Beveled Gers
|
1:1.46 ratio-Cast Iron Housing with Beveled Gers
|
|
weight
|
164kgs
|
245kgs
|
280kgs
|
|
Form factor
|
129x129x47
|
160x160x47
|
190x187x41
|
|
Quantity/FCL
|
80pcs/40'HQ
|
48pcs/40'HQ
|
40pcs/40'GP
|
